Background
Autonomous SaR robots can reduce human exposure to dangerous post-disaster environments. However, a significant challenge is their safe navigation through dynamic, cluttered spaces with moving obstacles. Existing control methods are often limited; they either assume a static environment, offer ad-hoc solutions that lack performance guarantees, or cannot be generalized.
This study sought to fill this gap by proposing a novel, integrated control architecture. It unified a computationally efficient motion planner that accounts for dynamic obstacles with a robust, tube-based model predictive control (TMPC) tracking system. This combination ensured safe, collision-free navigation towards targets while formally handling uncertainties and constraints, providing the reliability needed for real-world SaR missions.
Importantly, the framework operates in a stateless, perception-driven manner, meaning the robot does not rely on memory of past states, but instead navigates based solely on real-time environmental perception. This makes it more suitable for partially observable, unpredictable post-disaster environments.
The Study
This research detailed a novel, single-layer yet functionally bi-level control architecture designed to enable autonomous SaR robots to navigate dynamic and cluttered environments. The proposed framework strategically divides the complex navigation task into two interconnected systems to balance computational efficiency with robust performance.
The high-level component is a heuristic motion planner, which generates a nominal, collision-free path for the robot. This planner is a modified version of an existing obstacle-avoiding shortest path approach, critically enhanced to handle moving obstacles. It achieves this by predicting the future trajectories of dynamic obstacles and aggregating their positions over a prediction horizon into consolidated "obstacle belts," allowing for anticipatory, rather than merely reactive, collision avoidance.
The generated reference path is then passed to the low-level system: an optimal motion tracker based on TMPC. This component is responsible for steering the robot to closely follow the planned trajectory while explicitly accounting for real-world uncertainties. These include bounded external disturbances (like uneven terrain) and perception errors in estimating obstacle positions.
The TMPC formulation employs dynamic constraint tightening, ensuring the robot's actual state remains within a safe "tube" around the nominal plan, thus formally guaranteeing collision avoidance despite these uncertainties.
The two systems operate in a closed loop, meaning that if the TMPC encounters a situation where tracking the current path becomes infeasible, it signals the heuristic planner to request a new, updated trajectory. This integrated design provides a scalable and reliable solution for autonomous navigation in the challenging and unpredictable conditions of post-disaster scenarios.
The authors do also emphasize that the system’s stateless design reduces computational dependency on prior data, but it can still be extended to memory-augmented approaches such as SLAM for enhanced robustness if needed.
Study Findings
The simulation results demonstrated the superior performance and robustness of the proposed integrated heuristic motion planning and TMPC (HP+TMPC) architecture compared to the horizon-based lazy rapidly-exploring random tree (HL-RRT*) and artificial potential function (APF) methods.
In the complex, dynamic scenarios, both APF and HL-RRT* consistently failed to guide the robot to its target. APF was highly sensitive to parameter tuning, often resulting in the robot becoming stuck in livelocks, such as an eight-shaped path. HL-RRT* failed primarily because its lack of predictive modeling for moving obstacles led to paths that were quickly invalidated, causing endless re-planning cycles without success.
In contrast, HP+TMPC achieved a high success rate. Its ability to anticipate obstacle motion by forming "obstacle belts" allowed it to navigate high-risk scenarios, such as narrow corridors between dynamic and static obstacles, where HL-RRT* failed. While HL-RRT* sometimes found slightly shorter paths in less complex cases, its paths were often longer on average, and it required a high computational budget to succeed.
The mission time for HP+TMPC was generally competitive, though the researchers noted it could be further improved by explicitly including a time-minimization term in the TMPC objective function. The primary failures for HP+TMPC occurred when the heuristic planner unintentionally steered the robot into a "crushing zone" from which the TMPC could not recover within its computational constraints.
The study also highlighted that the framework achieved real-time feasibility even under limited computational budgets. With greater computational resources, it consistently converged to feasible solutions, demonstrating strong potential for real-world deployment.
Unlike many data-driven or learning-based navigation approaches, the proposed system does not depend on trained policies or large datasets. Instead, it offers formal safety guarantees through mathematical optimization, distinguishing it from reinforcement learning and hybrid planners that often lack such assurances.
Conclusion
In conclusion, this research successfully developed and validated a novel control architecture that enables autonomous SaR robots to navigate complex, dynamic environments with greater reliability. By combining a heuristic motion planner with a robust TMPC tracker, the system strikes a critical balance between computational efficiency and dependable performance.
One of the standout features is its ability to predict the movement of obstacles using so-called "obstacle belts," while still guaranteeing safety—even when faced with uncertainty. That’s a major step forward compared to existing methods, which often failed in testing. The authors describe their system as unified, perception-driven, and stateless, meaning it doesn’t rely on past data to make decisions. It’s also lightweight enough to run efficiently and flexible enough to support future upgrades, like optimizing for time or coordinating multiple robots.
Altogether, this work offers a solid, scalable approach that brings us closer to deploying autonomous robots in real-world disaster zones where making safe, fast decisions isn’t just a technical challenge, but a matter of saving lives.
Journal Reference
Rado, K., Baglioni, M., & Jamshidnejad, A. (2025). Enabling robots to autonomously search dynamic cluttered post-disaster environments. Scientific Reports, 15(1). DOI:10.1038/s41598-025-18573-y. https://www.nature.com/articles/s41598-025-18573-y
