VF-1 Vertical Machining System from Haas Automation, Inc .

The Haas VF-1 vertical machining center has 20" x 16" x 20" (508 x 406 x 508 mm) travels and is built utilizing vibration-damping cast-iron components. Like every Haas machine, the VF-1 represents years of ongoing refinement. Customer feedback, coupled with the relentless pursuit of perfection, sees advancements and design-enhancing changes incorporated directly into the production line every day.

The Haas VF-1 is a rugged, small-footprint vertical machining center that combines reliability and accuracy in a small-framed machine. The VF-1 has a 40-taper cartridge spindle driven by a 20 hp (14.9 kW) vector drive. The VF-1 produces either 75 ft-lb (102 Nm) of torque at a low 1400 rpm, or 250 ft-lb (339 Nm) at 450 rpm with the optional 2-speed gearbox -- and will also run up to 7500 rpm in 1.2 seconds for finishing aluminum. The Haas control features advanced tool management, single-button features, a 15" color LCD monitor and a USB port. With a long list of standard features and high-productivity options, the Haas VF-1 is one of the best values available today.

To find out more about all the special things that make a Haas vertical machining center perhaps the most popular machine tool in the world today, check out Options and Accessories.
