Background
Agriculture is increasingly adopting robotics to address labor shortages, sustainability pressures, and the demand for higher productivity. Earlier studies have explored modular robots with interchangeable components, while task-specific systems have demonstrated high precision in areas such as weed control.
However, these approaches come with trade-offs.
Many systems are bulky, limited to single functions, insufficiently tested across diverse field conditions, or too expensive for small-scale use. Commercial platforms often emphasize productivity, but at the cost of increased size and reduced affordability.
This study aims to bridge those gaps by proposing a lightweight, modular 4WD platform capable of handling grass cutting, debris crushing, and precision seeding within a serviceable two-unit design. Using simulation-based methods like energy modeling, coverage planning, robustness testing, and finite-element analysis, the research highlights the system’s potential for resilience, efficiency, and sustainability in campus and small-scale agricultural environments.
Platform Architecture and Analysis Framework
The robot is built around a vertically stacked, two-unit architecture. The lower unit features a steel frame housing the drivetrain, blower, and electronics, while the upper unit contains a high-capacity collection chamber with quick-release toolheads. Each wheel is independently powered, enabling skid-steer movement and zero-radius turning.
The modular attachments include:
- A height-adjustable grass trimmer
- A leaf crusher
- A precision seed dispenser with a rotating metering drum and adjustable gate
An adaptive cutting-height system, supported by prototype image-processing algorithms, is proposed to adjust trimming levels based on grass type.
The system integrates perception, decision-making, and actuation layers. Sensor fusion combines LiDAR, camera input, and an inertial measurement unit (IMU), with an Extended Kalman Filter used for localization and state estimation. For coverage planning, three strategies were evaluated - zigzag (boustrophedon), inward spiral, and concentric circles - with simulations showing that only the zigzag pattern ensures complete coverage of rectangular fields.
Energy modeling estimates operational runtimes of:
- ~1.2 hours in cutting mode
- ~2.0 hours in crushing mode
- ~8.0 hours in seeding mode
These are based on a 24 V, 50 Ah battery system. Robustness simulations indicate debris deflection rates above 95 %, slope-climbing capability up to ~25 degrees with under 20 % slip, and a stone-ingestion probability of around 10 %. The study also proposes biomass composting as a downstream sustainability pathway.
Overall, the findings suggest that the platform could deliver a balance of durability, efficiency, and multifunctionality suitable for smaller-scale operations.
Simulation-Based Validation
To assess real-world viability, the researchers conducted a series of robustness simulations.
A Monte Carlo analysis of 10,000 particles impacting the semi-circular bumper showed that more than 95 % of debris is deflected away from the cutter, with an ingestion rate of approximately 4.8 %, meeting design expectations. Additional simulations indicate that a protective guard covering 80 % of the cutter inlet reduces stone-ingestion probability to about 10 %.
Finite element analysis further supports the system’s structural integrity. The steel base frame experienced a maximum von Mises stress of just 0.004 MPa under a 15 N load, which is well below material limits. The aluminum upper structure showed similarly low stress under a 150 N load, with a consistent safety factor of 15, corresponding to an estimated failure threshold of 2250 N. The seed-dispenser assembly also demonstrated high stiffness, with minimal displacement and peak stress around 0.115 MPa, suggesting stable performance during operation.
When compared to existing systems such as MARS, Hefty, and SPARROW, the proposed platform stands out for integrating multiple functions into a single unit. While commercial solutions like Farming GT offer high productivity, they tend to be heavier and more expensive. This design attempts to strike a more practical balance between capability, cost, and deployability.
Conclusion
This study presents a modular 4WD autonomous platform that combines grass cutting, leaf crushing, and precision seeding within a compact, two-unit architecture. Simulation results indicate strong structural integrity, high debris deflection rates, and reliable operational performance across multiple functions. While these findings are promising, real-world validation through prototyping and field trials will be essential.
Future work will focus on building physical prototypes, conducting field testing, and further exploring biomass utilization strategies to confirm both performance and sustainability in practical settings.
Journal Reference
Kumar et al. (2026). Modular 4WD agricultural robot for cutting, collection, and precision seeding: design and simulation-based evaluation. Scientific Reports. DOI:10.1038/s41598-026-44388-6. https://www.nature.com/articles/s41598-026-44388-6
