Harmonic Drive AG Develop New Component Gear Set with Multiple Industry Applications

Harmonic Drive AG of Limburg, Germany, has developed an inventive type of component gear set, used in industrial service robots, medical technology, aerospace and semi-conductor manufacturing, that is considerably lighter and more compact than conventional gears, yet can deliver higher torque and achieve a reduction ratio range from 30:1 to 320:1 in just a single stage without backlash.

The company specified DuPont™ Vespel® TP thermoplastic bearing cages to play a key role in achieving low weight and compactness in its Harmonic Drive® CPL component sets. These wear-resistant Vespel® TP parts offer a low coefficient of friction against steel with good mechanical strength and toughness. They help ensure the lightweight, compact component sets operate reliably even at very high or low temperatures.

Performance Beyond Standard Engineering Plastics

Working closely with DuPont Performance Polymers (DuPont), Harmonic Drive AG developed the Vespel® TP bearing cages specifically for applications requiring superior resistance to aggressive, high-performance lubricants at high temperatures, or the ability to operate in a vacuum – performance beyond that of cages made from standard engineering plastics. The Vespel® TP bearing cages resist additive-enhanced greases and oils used to provide lifetime lubrication (approx. 30 000 hours), at ambient temperatures between –40°C and 120°C.

“Depending on the application, the forces transmitted from the ball bearings can induce high flexural stress into the cage clips, particularly during start-up, a change in speed, or a reverse in rotational direction. In light of the minimized wall thickness, extreme load cases can lead to premature cage clip wear or breakage in cages made from standard engineering polymers. In comparison, Vespel® TP bearing cages have proved to be durable and reliable under such conditions, even in extreme operating environments,” said Matthias Mendel, design and development manager at Harmonic Drive.

The company has extended the use of these components, in diameters from 15 mm to 130 mm, to other gear products, including its latest high-performance CobaltLine range.

Low Friction, Low Wear Vespel® TP parts

Vespel® TP parts combine low friction and low wear performance in lubricated and non-lubricated applications with the ease-of-processing into forms and shapes of standard thermoplastics, providing broad design freedom and suitability for mass production. They offer an outstanding combination of mechanical strength, chemical resistance to common fuels and lubricants, as well as a high continuous operating temperature with minimal out-gassing in vacuum environments. Other typical applications include journal bearings and sliding components, guide bushings and thrust washers.

Photo: Courtesy Harmonic Drive AG. DuPont™ Vespel® TP bearing cages (top) retain and guide the ball bearings in Harmonic Drive® gear units (bottom), and enable weight saving and compactness.

The Vespel® TP parts used in Harmonic Drive® gear units withstand high mechanical loads due to the material’s high flexural strength (215 MPa @ 23°C), high dimensional stability, exceptional creep resistance, and allow service at continuous operating temperatures up to 244°C (HDT).

DuPont offers a variety of high-performance polymer (predominantly polyimide) based Vespel® parts and shapes in thermoplastic TP and thermoset S product families, among others, with numerous grades in each product family that offer an optimum material solution for the specific demanding application.

DuPont (NYSE: DD) has been bringing world-class science and engineering to the global marketplace in the form of innovative products, materials, and services since 1802. The company believes that by collaborating with customers, governments, NGOs, and thought leaders we can help find solutions to such global challenges as providing enough healthy food for people everywhere, decreasing dependence on fossil fuels, and protecting life and the environment. For additional information about DuPont and its commitment to inclusive innovation, please visit
