Fujifilm to Expand Machine Vision Lens Lineup with FUJINON HF-XA Series High Performance Lenses

Fujifilm Corporation (President: Shigehiro Nakajima) has announced that it will release five eFUJINON HF-XA Seriesf high performance lenses as new addition in the lineup for Machine Vision system in early December. These new lenses support 3-megapixel 2/3h format and deliver edge-to-edge even sharpness and cover five different focal lengths.

HF-XA series

In manufacturing field it is becoming general that Machine Vision system recognizes the image to perform tasks such as positioning, classification, measurement and inspections automatically. The demand for the Machine Vision system is anticipated to make further growth with responding to the request for automation and streamlining work in the production lines.

To respond to current market demanding for more product efficiency and stricter quality management, Machine Vision systems also need to realize higher image recognition accuracy and processing speed. Manufacturers are offering Machine Vision cameras with large sensors, high resolution and high frame rate. The optical lenses for these cameras are also requested to realize high resolution to provide the edge-to-edge even sharpness to secure the recognition accuracy of the systems.

The FUJINON HF-XA series are high-performance fixed focal length lenses with supporting 3-megapixels 2/3h sensor format. The new lenses maintain their sharpness even when wide open under low light conditions or during the change of shooting distance. When used under diverse shooting conditions at various types of production lines, the lenses maintain edge-to-edge sharpness from the image center to all corners for higher image recognition accuracy. Instead of the 30mm-square form factor common for Machine vision cameras, the new series come in a cylindrical shape measuring ƒÓ29.5mm, thereby catering to the development of compact Machine Vision systems. Three mounting holes each are provided for the iris and focus rings so that the lenses can be mounted to Machine Vision from more flexible angles.

Tapping into optical technologies and precision processing / assembling technologies nurtured over many years, Fujifilm offers a wide variety of lenses for the digital age of premium imaging, including broadcast lenses and surveillance camera lenses. Also in the machine vision field, the company will continue to deliver an extensive lineup of products developed in pursuit of advanced performance, best imaging and high quality in order to meet the needs of all customers.

1. Product names, release date and pricing

Product name Focal length Release date Price
FUJINON@HF8XA-1 8mm Early December 2015 Open
FUJINON@HF12XA-1 12mm
FUJINON@HF16XA-1 16mm
FUJINON@HF25XA-1 25mm
FUJINON@HF35XA-1 35mm

2. Main features :

(1) Maintain high resolution even with aperture and working distance changed and edge-to-edge even sharpness from center to the corner under diverse shooting conditions for accurate image recognition.

The lenses support 3-megapixel 2/3h-format sensors. Even when wide open or during change of shooting distance, when image sharpness tends to be compromised, these lenses maintain edge-to-edge sharpness that fully resolves at the pixel pitch of 4.4ƒÊm for sensors of this class.

(2) Compact and lightweight body

All the lenses in this series sport a compact ƒÓ29.5mm cylindrical shape, more compact than the form factor of general Machine Vision system lenses (30mm-square), thereby contributing to reducing the overall system size.

(3) Designed for installation convenience

Three screw holes each are provided on the iris ring and focus ring for affixing the lens in place. When screwing down the lenses at the iris and focus lenses in tight spaces, you can choose from those positions for greater installation convenience.

3. HF-XA Seriesf main specifications

HF8XA-1 HF12XA-1 HF16XA-1 HF25XA-1 HF35XA-1
Focal length 8mm 12mm 16mm 25mm 35mm
Iris range(F. no) F1.6-F16 F1.6-F16 F1.6-F16 F1.6-F16 F1.9-F16
Angle of view
  • * When attached to a 2/3h camera
58.4‹x44.6‹ 40.1‹x30.3‹ 31.4‹x23.7‹ 20.0‹x15.0‹ 14.2‹x10.7‹
Working distance ‡]100mm ‡]100mm ‡]100mm ‡]100mm ‡]200mm
Operation Focus Manual
Iris Manual
Filter thread(mm) M25.5 x 0.5
Mount C-mount
Sensor size (max) 2/3h
TV distortion (%) -2.0 -1.3 -0.6 -0.1 0.1
Dimension (mm) ƒÓ29.5x51.5 ƒÓ29.5x51.5 ƒÓ29.5x46.0 ƒÓ29.5x46.5 ƒÓ29.5x41.5
Weight (ca.) (g) 79 79 71 72 60

* These product specifications and external appearances are as of the time of this press release (November 26, 2015) and subject to change without prior notice.
